Twister 2X
- Joystick Type
digital joystick(one-speed ~ five-speed) - Safety/Quality Approvals
CE EN 62368-1
| Transmitter Unit | |
|---|---|
| Frequency Range：433MHz Transmitter Range：100m Continuous Operating Time：25hrs Security ID code：65,536 sets Channel Spacing：25KHz & 50KHz Hamming Disyance：≧ 6 Frequency Control：VTCXO (PLL) Frequency Drift：< 3ppm @-10℃ ~ 75℃ Frequency Deviatuon：< 1ppm @25℃ Spurious Emission：> 60dBc | Transmitter Power：1.0mW Emission：FID Antenna Impedance：50Ω Enclosure Rating：IP66 Source Voltage：7.2V (2000mA) Current Drain：~ 80mA Operating Temperature：-10℃ ~ 75℃ Dimension：247 x 154 x 182 mm Weight：1,600g (with Battery) |
| Receiver Unit | |
|---|---|
| Frequency Range：433MHz Sensitivity：-125dBm Decoding Reference：FSK Security ID code：65,536 sets Channel Space：25KHz & 50KHz Hamming Distance：≧ 6 Frequency Control：VTCXO (PLL) Frequency Drift：< 3ppm @-10℃ ~ 75℃ Frequency Deviation：< 1ppm @25℃ Data Decoder Reference：Quartz Crystals (PLL) | Responding Time：100ms ~ 300ms Output Contact Rating：250V @10A Antenna Impedance：50Ω Enclosure Rating：IP66 Source Voltage：24-48VAC, 110-240VAC, 380-460VAC, 12-24VDC @50/60Hz. Power Consumption：36VA Operating Temperature：-10℃ ~ 75℃ Dimansion：417 x 309 x 167mm Weight：8,800g |
